Port Specifications and Schedule of Rates

Fleet Dock

Berthage

Bearing Capacity

Wharf Construction

Download Port of Argentia Specifications

Port Schedule of Rates

Schedule “B” Wharfage & Transfer Charges
Schedule of Rates

Schedule “C” Facility Storage Charges
Schedule of Rates

Schedule “D” Berthage Rates
Schedule of Rates

Download Schedule of Rates

Sorry, your submission has some errors that need to be corrected before you may continue.

Berth #	Length	Width	Draught	Wharf Height Low Tide	High Tide
1	150 m (490 ft.)	12 m (40 ft.)	11.0 m (36 ft.)	3.66m 4.00m	2.10m 2.40m
2	150 m (490 ft.)	12 m (40 ft.)	11.0 m (36 ft.)	3.66m 4.00m	2.10m 2.40m
3	130 m (420 ft.)	13.8 m (45 ft.)	8.5 m (28 ft.)	3.66m 4.00m	2.10m 2.40m

Berth	Capacity	Gross Vehicle Weight
1	2,500 kg/sq. metre (500 psf.)	45,885 kg (101,240 lbs.)
2	2,500 kg/sq. metre (500 psf.)	45,885 kg (101,240 lbs.)
3	5,000 kg/sq. metre (1000 psf.)	91,770 kg (201,894 lbs.)

Berth	Wharf Type	Construction	Deck Pad	Fendering
1	Marginal	Steel Pipe Piles with Concrete Caps	Reinforced Concrete	Round Rubber Angle D-fender
2	Marginal	Steel Pipe Piles with Concrete and Wood Caps	Reinforced Concrete	Round Rubber Angle D-fender
3	Marginal	Caisson Construction slab on grade	Reinforced Slab on grade	Rubber V-fender

Item	Description	Unit Basis	Rates (CAD)
1	All goods not otherwise specified
(a)	with a cubic content of less than 1 m3 per tonne	Tonne	2.96
(b)	with a cubic content equal to or greater than 1 m3 per tonne	Cubic metre	2.40
2	Automobiles, auto trailers, tractors	Each	6.56
3	Boats
(a)	not over 6m in length	Each	6.87
(b)	over 6 m but not over 10m in length	Each	16.38
(c)	over 10m in length	Each	32.77
4	Cement
(a)	in bulk	Tonne	1.06
(b)	in containers	Tonne	1.41
5	Fish
(a)	whole	Tonne	0.38
(b)	cured	Tonne	0.56
(c)	processed	Tonne	0.67
6	Lumber and timber, except plywood	Cubic metre	0.58
7	Metals, in ingots, pigs, blooms, bales, etc. (unfinished product)	Tonne	2.17
8	Motorcycles, snowmobiles, all terrain vehicles	Each	1.65
9	Gasoline, petroleum products and other liquid commodities
(a)	gasoline
(i)	in bulk	Kilolitre	0.89
(ii)	not in bulk	205 litre drum	0.27
(b)	other petroleum products
(i)	in bulk	Kilolitre	1.22
(ii)	not in bulk	205 litre drum	0.51
(c)	all other liquid commodities
(i)	in bulk	Kilolitre	1.93
(ii)	not in bulk	205 litre drum	0.58
10	Ores, alum, barytes, sulphur, soda ash, calcium chloride, quick lime	Tonne	1.09
11	Ore concentrates	Tonne	1.80
12	Plywood	Tonne	2.09
13	Potatoes and root vegetables	Tonne	0.87
14	Pulpwood, firewood, in stacked cords	Cubic metre	0.22
15	Salt
(a)	for fish curing	Tonne	0.45
(b)	for other purposes	Tonne	0.97
16	Sand, stone, gravel	Tonne	0.71
17	Scrap metals	Tonne	2.36
18	Trucks, tractor-trailers, trailers, buses, in addition to the charge on content	Metre of length	2.09
19	Minimum charge	Per shipment or consignment	1.06
20	Containers, 6m in length and over, loaded, in addition to wharfage charges on their contents	Each	35.66
21	Containers, less than 6 meters	Each	21.00
22	Crane	Per Day	1.00 per tonne of lifting capacity

Item	Description	Unit Basis	Rates (CAD)
1	Storage for goods on wharf, per day or part thereof	square metre	0.15
2	Storage for goods elsewhere at a public port facility, per day or part thereof	square metre	0.11

Item	Description	Unit Basis	Rates (CAD)
3	Berthage charge on a vessel that is loading or unloading or engaged in any other commercial activity elsewhere than at a float
(a)	per hour or part thereof	metre of length	0.17
(b)	maximum per day	metre of length	1.90
(c)	minimum berthage charge	per vessel	24.84
4	Security Services
(a)	Supervisor – Security	per hour	50.00
(b)	Security Services – Port Attendant	per hour	23.50
